2-Year Outdoor Inkjet Vinyl

ق-YEAR OUTDOOR INKJET VINYL – WHITE BUBBLE-FREE LINER

2-Year Outdoor Inkjet Vinyl is a white printable vinyl material designed for displays, illuminated and non-illuminated signage, and windows. It features a 0.11 mm PVC face film, 4-way stretchability, good ink absorption, and compatibility with Eco-Solvent and UV inks. A removable solvent acrylic adhesive and PE-coated liner with air-release channels complete the material structure for outdoor visual applications with a 2-year application period.

1. 2-Year Outdoor Inkjet Vinyl for Outdoor Visual Applications

2-Year Outdoor Inkjet Vinyl is a white vinyl material developed for visual applications requiring an outdoor application period of 2 years. It is available under product code MC501QDTK2Y and can be supplied in multiple roll widths for different printing and display formats.

The face film uses PVC with a thickness of 0.11 mm. Its material structure provides:

• 4-way stretchability
• Good ink absorption
• Compatibility with Eco-Solvent and UV inks

The white vinyl format is suitable for printed displays, illuminated signage, non-illuminated signage, and windows. Its printable surface supports visual graphics produced with compatible ink technologies.

The product is available in roll widths of 36.0", 42.1", 50.0", 53.1" and 59.8", with a roll length of 54.7 Y. Metric roll dimensions are also available in several widths.

2-Year Outdoor Inkjet Vinyl for signage, displays and windows

2. Technical Structure and Specifications

2-Year Outdoor Inkjet Vinyl combines a PVC face film with a removable solvent acrylic adhesive and a double-sided PE-coated liner.

• Product code: MC501QDTK2Y
• Color: White
• Outdoor application period: 2 years
• PVC face film thickness: 0.11 mm
• Stretchability: 4-way
• Ink absorption: Good
• Ink compatibility: Eco-Solvent and UV inks
• Adhesive: Removable solvent acrylic adhesive
• Adhesive thickness: 33 μm
• Adhesive performance: Strong and stable adhesion with clean, residue-free removal
• Liner: 2-side PE-coated liner
• Liner structure: One release-coated side with air-release channels
• Liner thickness: 140 μm
• Compliance: REACH compliance documentation available

The 33 μm removable solvent acrylic adhesive provides strong and stable adhesion while allowing clean, residue-free removal. This adhesive structure is combined with a 140 μm double-sided PE-coated liner featuring one release-coated side and air-release channels.

Available roll sizes include:

• 36.0" × 54.7 Y
• 42.1" × 54.7 Y
• 50.0" × 54.7 Y
• 53.1" × 54.7 Y
• 59.8" × 54.7 Y

Metric options include:

• 0.914 m × 50 m
• 1.07 m × 50 m
• 1.27 m × 50 m
• 1.35 m × 50 m
• 1.52 m × 50 m

The combination of a 0.11 mm PVC face film, 33 μm removable solvent acrylic adhesive, and 140 μm PE-coated liner provides a defined material structure for outdoor inkjet vinyl applications.

3. Applications for Displays, Signage and Windows

2-Year Outdoor Inkjet Vinyl is suitable for several types of visual display applications, including:

• Displays
• Illuminated signage
• Non-illuminated signage
• Windows

Its compatibility with Eco-Solvent and UV inks makes it suitable for printing workflows using these ink technologies. The 4-way stretchable PVC face film provides flexibility for application across visual surfaces.

The white face film can be used for printed graphics where a white vinyl substrate is required. Multiple roll widths allow the material to be supplied in different formats, from 36.0" to 59.8", with corresponding metric widths from 0.914 m to 1.52 m.

For outdoor visual materials with a 2-year application period, the product combines printable PVC film, removable solvent acrylic adhesive, and an air-release liner structure. These characteristics make it applicable to displays, illuminated and non-illuminated signage, and window graphics.

Long An Sticker Manufacture Company Limited – Manufacturer of decal paper and vinyl sticker paper for commercial printing applications.

Contact Long An Sticker Manufacture Company Limited to discuss 2-Year Outdoor Inkjet Vinyl specifications, available roll sizes, and application requirements.
