WEDGE WIRE CYLINDRICAL FILTER
The wedge wire cylindrical filter is used in the flow from ion exchange vessels and serves as a means to minimize ion exchange resin loss. We can design traps to capture carrier particles of any size. With continuous slot openings, the traps provide sufficient open area to allow smooth flow. Haixing offers a range of resin traps suitable for almost every application. All are available in a variety of construction materials with multiple flange connections and housings. In vessels using hydrochloric acid for regeneration, resin traps must be constructed using Hastelloy.
➩ Applications for Wedge Wire Cylindrical Filter:
- Backwash filtration of raw oil in petrochemical hydrogenation systems
- Recovery of precious metal catalysts in hydrogenation systems
- Automatic backwash filtration of oil outside catalysts
- Liquid sulfur filter cleaning
- Lubricants and heat transfer oil filtration
- Raw paraffin and paraffin product filtration
- Backwash filtration of rich amine liquids in amine desulfurization systems
- High-temperature coal gas, flue gas, and oil gas purification
- Raw materials for paraffin and backwash filtration
- Efficient pressurized gas-liquid mixed backwash filtration technology
➩ Features of Wedge Wire Cylindrical Filter:
- Filter made of stainless steel wedge wire with V-shaped screen slots, effectively blocking resin impurities.
- Wedge wires are arranged circumferentially on support rods, ensuring screen filtration area without clogging and avoiding impurity concentration.
- All resin traps are welded for durability and long service life.
- After a period of use, backwash filtration is possible for multiple uses.
➩ Technical Specifications:
✔ Materials: Low carbon steel, low galvanized steel (LCG), plastic sprayed steel, stainless steel (304, 316, 2205, 2507, 904, etc.)
✔ Wedge wire (mm):
- Width: 1.50, 1.80, 2.30, 3.00, 3.30, 3.70
- Height: 2.20, 2.50, 2.70, 3.60, 4.30, 4.70, 5.60, 6.30, 7.00
✔ Support rods (mm):
- Width: 2.30, 3.00, 3.30, 3.70
- Height: 2.70, 3.60, 4.70, 5.60, 6.30
- Wire diameter: 2.50 mm – 6.0 mm
- Different diameters from 1 inch to 45 inches
- Length: up to 3 meters
- Slot size: 0.03, 0.05, 0.08, 0.10, 0.15, 0.20, 0.25, 0.30, …, up to 3.00 mm can also be made upon request.
➩ Note: Other specifications can be customized according to your requirements.
Additionally, we also provide dust filters, oil filters, and more. We warmly invite our customers to inquire.
